Is the Dell PowerEdge R760xs Rack Server new or refurbished?

All listed Dell PowerEdge R760xs Rack Server units are brand new with manufacturer warranty unless explicitly marked as Refurbished or Used.

What is the delivery time across Pakistan?

In-stock items ship within 24-48 hours from Lahore. Deliveries to Karachi, Islamabad, Faisalabad and Rawalpindi typically reach in 2-4 working days.

Does the price include GST and installation?

Quotations are itemised — hardware, GST and optional installation services are listed separately so you can pick what you need.

Do you provide installation and after-sales support?

Yes. Toprated provides installation, configuration and ongoing technical support for every product we supply, backed by ISO 9001 / ISO 27001 certified processes.

Dell PowerEdge R760xs Server Price in Pakistan

Configurable to your workload

Pick alternative CPU, memory, storage or warranty and submit — we will price your exact build within one business day. The base configuration is captured under Detailed Specification.

Build to order

Processor

Both CPUs in the dual-socket configuration are the same SKU. Other Intel Xeon Scalable 4th-Gen SKUs available on request — share your workload and we will recommend the optimal binning.

Intel Xeon Silver 4514Y Base 2.0 GHz · 16C/32T · 30 MB · 150 W · DDR5-4400 (base, 338-CPBZ)

Intel Xeon Gold 5416S 2.0 GHz · 16C/32T · 30 MB · 150 W · DDR5-4400 (338-CHSL) — higher base clock & cache.

Intel Xeon Silver 4510 2.4 GHz · 12C/24T · 30 MB · 150 W · DDR5-4400 — higher single-thread.

Intel Xeon Gold 6442Y 2.6 GHz · 24C/48T · 60 MB · 225 W · DDR5-4800 — vSphere / VDI host.

Intel Xeon Platinum 8462Y+ 2.8 GHz · 32C/64T · 60 MB · 300 W · DDR5-4800 — SQL / SAP / large VMs.

Other Intel Xeon — specify SKU Any Intel Xeon Scalable 4th-Gen (Sapphire Rapids) or 5th-Gen (Emerald Rapids) SKU supported by the R760xs motherboard. We confirm compatibility before quoting.

Memory

Base = 128 GB (2× 64 GB DDR5 RDIMM 5600 MT/s). R760xs supports 16 DIMM slots up to 1 TB DDR5 RDIMM. Pick capacity by VM density and workload.

128 GB (2× 64 GB DDR5 5600 RDIMM) Base Base configuration — file/print, AD, light virtualization.

256 GB (4× 64 GB DDR5 5600 RDIMM) Mid-size virtualization, SQL Standard, mid-size databases.

512 GB (8× 64 GB DDR5 5600 RDIMM) Dense ESXi / Hyper-V host, large databases, VDI.

1 TB (16× 64 GB DDR5 5600 RDIMM) Memory-bound workloads, in-memory analytics, large VDI host.

Other memory configuration — specify Any valid DIMM count up to 16 sticks of DDR5 RDIMM. Tell us total capacity and we will pick the right DIMM count for performance.

Storage

Chassis: 8× 2.5" SAS/SATA hot-plug bays + PERC H755 SAS Front. NVMe back-plane available on request. Pick capacity, drive type and RAID protection by I/O profile.

2× 600 GB SAS 10K — base Base Smart Selection Flexi base — boot/OS or small DB.

4× 1.2 TB SAS 10K (RAID-10) General-purpose host — ~2.4 TB usable.

4× 2.4 TB SAS 10K (RAID-10) File server / mid-size DB — ~4.8 TB usable.

4× 1.92 TB SSD SAS RI (RAID-10) Read-intensive virtualization host — ~3.84 TB usable.

8× 3.84 TB SSD SAS MU (RAID-6) Mixed-use SSD — ~23 TB usable, high IOPS + capacity.

8× 3.84 TB NVMe (back-plane swap) All-NVMe — lowest latency for SQL/SAP workloads.

Other storage configuration — specify Mix drive types, RAID levels and tier sizes — describe required usable capacity, IOPS target and redundancy. NVMe back-plane swap available.

Networking

Base ships with on-board 2× 1 GbE + OCP 3.0 4× 1 GbE + Emulex FC32 dual-port HBA. 10/25/100 GbE OCP and Mellanox/Broadcom NICs available.

Base: 2×1 GbE LOM + 4×1 GbE OCP + FC32 HBA Base

Add Broadcom 57414 Dual-Port 25 GbE OCP

Add Mellanox ConnectX-6 Lx Dual-Port 25 GbE

Add Intel E810-CQDA2 Dual-Port 100 GbE

Power Supply

Base is dual 800 W Mixed-Mode Titanium. Upgrade for higher-power CPUs / GPUs.

Dual 800 W Mixed-Mode Titanium Base

Dual 1100 W Mixed-Mode Titanium

Dual 1400 W Mixed-Mode Titanium

Dual 1800 W (240 Vac) Titanium

Warranty / Support

Pick the SLA aligned with your production criticality. ProSupport Plus 4-hour Mission-Critical available for tier-0 workloads.

Basic Next Business Day · 36 months Base 709-BBHD — included in base.

ProSupport Next Business Day Onsite · 36 months 865-BBOJ — recommended upgrade.

ProSupport Plus 4-hour Mission-Critical · 36/60 months Tier-0 production / banking / telco.

Operating System (factory-installed)

Base ships with no OS. Factory-install or local-install available for all major server OSes.

No Operating System Base

VMware vSphere ESXi 8

Microsoft Windows Server 2022 / 2025 Standard / Datacenter

Red Hat Enterprise Linux 9

Ubuntu Server 22.04 / 24.04 LTS

Proxmox VE 8

Quantity

Additional notes

Full name *

Company

Work email *

Phone *

Confidential. Response within one business day.

Form Factor	2U Rack
Chassis	2.5" Chassis with up to 8 Hard Drives (SAS/SATA), PERC11 (321-BJDP)
CPU (base)	2× Intel Xeon Silver 4514Y · 2.0 GHz · 16C/32T · 30 MB L3 · 16 GT/s · 150 W · DDR5-4400
CPU sockets	Dual socket (Intel Xeon Scalable 4th Gen / Sapphire Rapids)
Heatsink	Standard Heatsink × 2 (412-BBBQ)
Memory profile	Performance Optimized · 5600 MT/s RDIMMs
Memory (base)	2× 64 GB RDIMM 5600 MT/s Dual Rank — 128 GB total (370-BBRN)
Storage controller	PERC H755 SAS Front, Unconfigured RAID (405-AAZB)
Storage (base)	2× 600 GB SAS ISE 12 Gbps 10K 512n 2.5" Hot-Plug (161-BCDJ)
Networking — LOM	Broadcom 5720 Dual Port 1 Gb On-Board LOM (329-BKGF)
Networking — OCP	Broadcom 5720 Quad Port 1 GbE BASE-T Adapter · OCP NIC 3.0 (540-BCOB)
Fibre Channel HBA	Emulex LPe35002 Dual Port FC32 · PCIe Low Profile (406-BBTM)
Riser	Riser Config 1 — Half Length, Low Profile, 3×16 + 1×8 + 2×16 (Gen5) (330-BCDQ)
TPM	Trusted Platform Module 2.0 V6 (461-AAIG)
Boot device	BOSS Blank — BOSS-N1 / Internal Dual M.2 available on request
BIOS / Boot mode	UEFI BIOS with GPT Partition · Power Saving BIOS settings
Cooling	Standard Fan × 5 (750-ADDY)
Power Supply	Dual (1+1) Redundant, Hot-Plug PSU — 800 W Mixed-Mode 100–240 Vac Titanium (450-AIQX)
Power Cords	2× C13/C14 Jumper Cord — 4 m 250 V 10 A (492-BBLO)
Bezel	PowerEdge 2U Standard Bezel (325-BEVI)
Rails / Cable Mgmt	ReadyRails Sliding Rails (B21) + 2U Cable Management Arm (770-BECC / 770-BDRQ)
Management	iDRAC9 Enterprise 16G · Dell Connectivity Module · iDRAC Group Manager · Legacy Password (528-CTIC)
Operating System	No Operating System (611-BBBF) — Windows Server, RHEL, Ubuntu, ESXi available on request
Warranty (base)	Basic Next Business Day 36 Months — ACDTS (709-BBHD)
Warranty (upgrade)	ProSupport Next Business Day Onsite 36 Months — ACDTS (865-BBOJ)
Marking	CCC Marking, No CE Marking (389-FBXX)
Dell SKU (base)	210-BGLV — Dell PowerEdge R760xs

Form Factor

2U Rack

Chassis

2.5" Chassis with up to 8 Hard Drives (SAS/SATA), PERC11 (321-BJDP)

CPU (base)

2× Intel Xeon Silver 4514Y · 2.0 GHz · 16C/32T · 30 MB L3 · 16 GT/s · 150 W · DDR5-4400

CPU sockets

Dual socket (Intel Xeon Scalable 4th Gen / Sapphire Rapids)

Heatsink

Standard Heatsink × 2 (412-BBBQ)

Memory profile

Performance Optimized · 5600 MT/s RDIMMs

Memory (base)

2× 64 GB RDIMM 5600 MT/s Dual Rank — 128 GB total (370-BBRN)

Storage controller

PERC H755 SAS Front, Unconfigured RAID (405-AAZB)

Storage (base)

2× 600 GB SAS ISE 12 Gbps 10K 512n 2.5" Hot-Plug (161-BCDJ)

Networking — LOM

Broadcom 5720 Dual Port 1 Gb On-Board LOM (329-BKGF)

Networking — OCP

Broadcom 5720 Quad Port 1 GbE BASE-T Adapter · OCP NIC 3.0 (540-BCOB)

Fibre Channel HBA

Emulex LPe35002 Dual Port FC32 · PCIe Low Profile (406-BBTM)

Riser

Riser Config 1 — Half Length, Low Profile, 3×16 + 1×8 + 2×16 (Gen5) (330-BCDQ)

TPM

Trusted Platform Module 2.0 V6 (461-AAIG)

Boot device

BOSS Blank — BOSS-N1 / Internal Dual M.2 available on request

BIOS / Boot mode

UEFI BIOS with GPT Partition · Power Saving BIOS settings

Cooling

Standard Fan × 5 (750-ADDY)

Power Supply

Dual (1+1) Redundant, Hot-Plug PSU — 800 W Mixed-Mode 100–240 Vac Titanium (450-AIQX)

Power Cords

2× C13/C14 Jumper Cord — 4 m 250 V 10 A (492-BBLO)

Bezel

PowerEdge 2U Standard Bezel (325-BEVI)

Rails / Cable Mgmt

ReadyRails Sliding Rails (B21) + 2U Cable Management Arm (770-BECC / 770-BDRQ)

Management

iDRAC9 Enterprise 16G · Dell Connectivity Module · iDRAC Group Manager · Legacy Password (528-CTIC)

Operating System

No Operating System (611-BBBF) — Windows Server, RHEL, Ubuntu, ESXi available on request

Warranty (base)

Basic Next Business Day 36 Months — ACDTS (709-BBHD)

Warranty (upgrade)

ProSupport Next Business Day Onsite 36 Months — ACDTS (865-BBOJ)

Marking

CCC Marking, No CE Marking (389-FBXX)

Dell SKU (base)

210-BGLV — Dell PowerEdge R760xs

Dell PowerEdge R760xs Rack Server
